Composite panels for ship and yacht building
Lightweight construction with INNOVATIVE materials
Especially in shipbuilding, special requirements are made on the elements to be used. We offer many different solutions that satisfy the high demands, for example on the moisture and UV resistance. Moreover, our elements offer a low weight and stand-out with their outstanding mechanical properties.
COSMO® Tech - GFK
GRP on both sides, TK-core
Top coats
Glass-fibre reinforced plastics (GRP)
Core material
Thermoplastic plastics (TP) (also available in XPS)
Formats (mm)
2,000 x 1,800 / 4,000 x 2,000 / 2,300 x 1,250
2,000 x 1,250 / 3,000 x 1,800 / 3,000 x 1,500
Other dimensions on request
COSMO® Tech - HPL
HPL on both sides, TK core
Top coats
High-pressure laminated panels (HPL)
Core material
Thermoplastic plastics (TP) (also available in XPS)
Standard sizes (mm)
2,800 x 1,860, 2,800 x 2,070, other dimensions on reques
Colours
Different colours are possible
COSMO® Plan S integral rigid foam panel
The white surfaces have a noble satin effect. They are ideal for ceiling elements as well as for use in sanitary areas.
Special Properties
- Good processing properties
- Fine, smooth surface
- Weather resistant & UV stable
- Versatile use
- Pressure resistant according to DIN EN ISO 844: >3 Mpa
- Shore D according to DIN EN ISO 868:: ̴ 75
Formats (Length x Width x Height in mm):
3,000 x 1,250 x 8-30 mm
3,000 x 1,560 x 10 / 19 mm
COSMO® TP - an innovative construction material
(TP=thermoplastic plastics)
The advantage of this foam is the unique combination of material and processing properties. High structural strength at low weight and excellent temperature stability are the most important factors that distinguish COSMO® TP from traditional core materials.
The closed cellular structure prevents the moisture absorption, making it ideal for the use in damp rooms. Another important advantage is its recyclability. It makes COSMO® TP attractive particularly for applications focusing on "eco-friendliness".
Special Properties
- Minimum absorption of humidity
- Outstanding mechanical characteristics
- Low weight
- Screwable
- Durably moisture-resistant
- Swelling-resistant, i.e. no changes of dimensions
- High pressure resistance
- Environment-friendly core material (100% recyclable)
Film lamination technology
More than 200 different wood decors and Uni-films available ex warehouse
With our state-of-the-art lamination technology and our long-term experience, we are offering a comprehensive service. Thanks to a special hot-melt adhesive system, a large variety of surfaces can be laminated on highly diverse carrier plates. Only DIN-certified films and carrier materials are processed. To ensure the best quality for you: durable, weather- and
UV-resistant.
